RF4 RF-6565TVD2-YS010W 6.5X-65X Trinocular Stereo Microscope with 10 inch HD Monitor for Electronics Repair
by RF4
$22,080.00
Delivered in 10-15 Days.
more info
Orders from overseas warehouse are delivered to our customers within 10-15 working days. We have a dedicated team to keep things moving quickly, and we will keep you updated on your order via SMS or email.
All-Inclusive Pricing.
more info
The price you see is the price you pay. Price includes any Customs, Insurance and Courier fees. Absolutely no hidden fees. We also take care of customs clearance.
Hassle-Free returns For 7 Days.
more info
View our Return Policy for more info.
- 【6.5X-65X Continuous Zoom】Professional trinocular stereo microscope with big continuous zoom range from 6.5X to 65X magnification for versatile observation needs.
- 【10 inch HD Monitor with 16MP Camera】Built-in 16MP HD camera with 10-inch monitor display enables real-time viewing and synchronous zoom with eyepiece observation.
- 【45-Degree Ergonomic Design】Features 45-degree inclined 360-degree swiveling trinocular head for comfortable extended use and flexible viewing angles.
- 【Professional LED Ring Light】144 adjustable LED ring light provides uniform illumination with white light color for optimal specimen visibility and detail clarity.
- 【Multifunctional Aluminum Base】Robust aluminum alloy repair base with specialized grooves, anti-slip silicone pad, and precision adjustment capabilities for stable operation.
- 【Synchronous Zoom Technology】Monitor and eyepiece synchronous zoom function allows seamless switching between visual observation and digital display without refocusing.
Specifications:
- Magnification Range: 6.5X to 65X Continuous Zoom
- Head Type: 45-degree Inclined 360-degree Swiveling Trinocular
- Eyepiece: WF10X/22MM Adjustable Focus
- Objective Lens: 0.65-6.5X
- Camera Connector: 1/2 CTV
- Barlow Lens Options: 0.5X & 0.7X & 2.0X (Optional)
- Monitor Size: 10 inch
- Camera Resolution: 16MP
- Stand Dimensions: 410 x 300mm
- Column Specifications: 240mm φ32mm Pillar
- Base Size: 410 x 300mm
- Silicone Pad Size: 330 x 198mm
- Column Aperture: 32mm
- Lens Aperture: 76mm
- Center Distance: 155mm
- Lifting Range: 50mm
- Eyepiece Magnification: 10X
- Eyepiece Field of View: 22mm
- Eyepiece Matching Size: 30mm
- LED Light Count: 144 LEDs
- LED Light Input: AC 100~240V 50/60Hz
- LED Light Output: DC 12V, Max 700mA
- LED Light Inside Diameter: 60mm
- Light Type: White LED
- CTV Adapter Material: All Metal (Aluminum Alloy and Copper Chrome-plated)
In the box
- 1 x Microscope
- 1 x Aluminum Alloy Plate
- 1 x Silicone Pad
- 1 x HD Monitor
- 1 x 144 LED Light
- 1 x Dustproof Lens
- 1 x 0.5X CTV Lens
